Motion of a charged particle in a combined magnetic and electric field

A charged particle follows a curved path in a magnetic field. In an electric field, the particle tends to accelerate in a direction parallel/antiparallel to the electric field depending on the nature of charge on the particle. In a combined electric and magnetic field, the particle moves along a helical path.

In this animation, there’s a magnetic and an electric field present in +x direction under whose influence the positively charged particle follows a helical path.

Importing necessary modules

import itertools

import numpy as np

import fury

Let’s define some variable and their description:

• radius_particle: radius of the point that will represent the particle (default = 0.08)

• initial_velocity: initial velocity of the particle along +x (default = 0.09)

• acc: acceleration of the particle along +x (due to the electric field) (default = 0.004)

• time: time (default time i.e. time at beginning of the animation = 0)

• incre_time: value by which time is incremented for each call of timer_callback (default = 0.09)

• angular_frq: angular frequency (default = 0.1)

• phase_angle: phase angle (default = 0.002)

radius_particle = 0.08
initial_velocity = 0.09
acc = 0.004
time = 0
incre_time = 0.09
angular_frq = 0.1
phase_angle = 0.002

Creating a scene object and configuring the camera’s position

scene = fury.window.Scene()
scene.zoom(1.2)
scene.set_camera(
    position=(10, 12.5, 19), focal_point=(3.0, 0.0, 0.0), view_up=(0.0, 0.0, 0.0)
)
showm = fury.window.ShowManager(
    scene, size=(800, 600), reset_camera=True, order_transparent=True
)

Creating a blue colored arrow which shows the direction of magnetic field and electric field.

color_arrow = fury.window.colors.blue  # color of the arrow can be manipulated
centers = np.array([[0, 0, 0]])
directions = np.array([[1, 0, 0]])
heights = np.array([8])
arrow_actor = fury.actor.arrow(
    centers,
    directions,
    color_arrow,
    heights,
    resolution=20,
    tip_length=0.06,
    tip_radius=0.012,
    shaft_radius=0.005,
)
scene.add(arrow_actor)

Initializing the initial coordinates of the particle

x = initial_velocity * time + 0.5 * acc * (time**2)
y = np.sin(angular_frq * time + phase_angle)
z = np.cos(angular_frq * time + phase_angle)

Initializing point actor which will represent the charged particle

color_particle = fury.window.colors.red  # color of particle can be manipulated
pts = np.array([[x, y, z]])
charge_actor = fury.actor.point(pts, color_particle, point_radius=radius_particle)
scene.add(charge_actor)

vertices = fury.utils.vertices_from_actor(charge_actor)
vcolors = fury.utils.colors_from_actor(charge_actor, "colors")
no_vertices_per_point = len(vertices)
initial_vertices = vertices.copy() - np.repeat(pts, no_vertices_per_point, axis=0)

Initializing text box to display the name of the animation

tb = fury.ui.TextBlock2D(bold=True, position=(100, 90))
m1 = "Motion of a charged particle in a "
m2 = "combined electric and magnetic field"
tb.message = m1 + m2
scene.add(tb)

Initializing counter

counter = itertools.count()

end is used to decide when to end the animation

end = 200

This will be useful for plotting path of the particle

coor_1 = np.array([0, 0, 0])

Coordinates to be plotted are changed every time timer_callback is called by using the update_coordinates function. The wave is rendered here.

def timer_callback(_obj, _event):
    global pts, time, incre_time, coor_1
    time += incre_time
    cnt = next(counter)

    x = initial_velocity * time + 0.5 * acc * (time**2)
    y = np.sin(10 * angular_frq * time + phase_angle)
    z = np.cos(10 * angular_frq * time + phase_angle)
    pts = np.array([[x, y, z]])

    vertices[:] = initial_vertices + np.repeat(pts, no_vertices_per_point, axis=0)

    fury.utils.update_actor(charge_actor)

    # Plotting the path followed by the particle
    coor_2 = np.array([x, y, z])
    coors = np.array([coor_1, coor_2])
    coors = [coors]
    line_actor = fury.actor.line(coors, fury.window.colors.cyan, linewidth=3)
    scene.add(line_actor)
    coor_1 = coor_2

    showm.render()

    # to end the animation
    if cnt == end:
        showm.exit()

Run every 15 milliseconds

showm.add_timer_callback(True, 15, timer_callback)
showm.start()
fury.window.record(showm.scene, size=(800, 600), out_path="viz_helical_motion.png")
